Name: Clion-Marine Chiller CH-IN 51,0 CAN - 120623
SKU: CHCMCHINV51CAN
Availability: InStock

Clion-Marine Chiller CH-IN 51,0 CAN – 120623

€11,061.60

Chillers

Full inverter Reverse cycle chillers in stainless steel housing.
No inductive loads at start up, low energy consumption and easy to install
Integrated automatic fuses with manual reset.
Eco modus for running on low shore supplies.
Control box with prewired EMC protected cable loom , which can be in-stalled a maximum of 0,8-1,2 mtr from the chiller (except CH-IN 270.0).

SKUCHCMCHINV51CAN

CategoriesOnline Shop

Chiller package

The Clion-Marine chiller package consists of the following items: chiller, complete prewired EMC protected control box and cable loom (0,8-1mtr), mounting kit control box (preinstalled at front of the chiller), touch screen display, Vimar black bezel, RJ45 cable 10 mtr.

Product: Clion-Marine Chiller
Model: CH-IN 51,0 CAN
Part Number: CM0000120623
Capacity (BTU/h): 16.300 – 51.500
Nominal Capacity (kW): 4,7 – 15,1
Maximum Capacity (BTU/h): 67.000
Maximum Capacity (kW): 19,5
Voltage (±10%): 200-240V / 50/60Hz / 1F
Power consumption (A): 4,18 – 13,95
Power consumption (start) (A): <2
Weight (kg): 56,00
Seawater connection: 3/4” / 19mm
Chilled water connection: 1” / 25,4mm
Dimensions (mm): 564 x 360 x 455
Control box dimensions (WxDxH): 340 x 245 x 250
Cable length control box: 0,8 m
Recommended fuse size: 25A
Drain connection (mm): 12 (4x)
Sea waterflow (m³/h): 2,52
Chilledwaterflow (m³/h): 2
Reference / Date: 120623
